H65T006XX 650X Tail Pitch Assembly

H65T006XX 650X Tail Pitch Assembly

Instruction:
● T-REX metal tail pitch assembly features high precise bearing structure and high rigid CNC processes aluminum alloy material, and therefore this refitting component is absolutely helpful for the accuracy of flying movement control and the stable of the flight.
● Suitable for T-REX 650X.

Specification:
● Slider Shaft x 1(Φ8x7x17.6mm)
● Bearing holder x 1(13.5x12.5x9.5mm)
● Bearing mount washer x 1(Φ7xΦ8.3x3.5mm)
● Control link x 2(Φ12.75xΦ6x3.9mm)
● 700 Collar x 2(Φ2.5xΦ3.5x4mm)
● 600 Metal T type arm x 1(27x8x11.2mm)
● Bearing MR117ZZ x 2(Φ7xΦ11x3mm)
● Collar screw x 2(M2x8mm)
● Socket Button Head Collar Screw x 2(M2.5x8mm)
